Diamond DA 62
Diamond DA 62
| Engine | 2x Austro Engine AE330 turbocharged common-rail injected 2.0 liter jet fuel engine with 180 HP and EECU single lever control system |
| Propeller | 2x MT propeller MTV-6-R-C-F/CF 194-80 3-blade constant speed propeller |
| Fuel grades | Jet A-1, Jet A, TS-1 (Russia, Ukraine), RT (Russia, Ukraine), No. 3 Jet Fuel (China), JP-8 |
| Max. cruise speed (14,000 ft, MCP) | 356 km/h TAS | 192 kts TAS |
| Cruise speed at 85% (12,000 ft) | 333 km/h TAS | 180 kts TAS |
| Stall speed, landing configuration | 126 km/h CAS | 68 kts CAS |
| Max.Rate of climb (MSL) | 5.2 m/s | 1,028 ft/min |
| Max. range (FL160, 50% PWR) incl. climb, no reserves | 2,358 km | 1,288 nm |
| Fuel consumption at 60% (12,000 ft) in total | 44.7 l/h | 11.8 US gal/h |
| Take-off performance (MSL, ground roll / take-off obstacle) | 480 m / 883 m | 1,574 ft / 2,730 ft |
| Landing performance (MSL, ground roll / landing distance) | 441 m / 779 m | 1,446 ft / 2,555 ft |
| Certified service ceiling | 6,096 m | 20,000 ft |
| Single engine service ceiling (MTOM, ISA, rate of climb: 50 ft/min.) | 3,354 m | 11,000 ft |
| Single engine absolute ceiling (MTOM, ISA, rate of climb: 0 ft/min.) | 4,116 m | 13,500 ft |
| Max. demonstrated crosswind | 46 km/h | 25 kts |
| Seats | Upto 7 | Upto 7 |
| Empty weight without options | 1,598 kg | 3,523 lbs |
| Max. useful load | 702 kg | 1,545 lbs |
| Max. take-off mass | 2,300 kg | 5,071 lbs |
| Max. usable fuel capacity | 327 l / 261 kg | 86.4 US gal / 576 lbs |
| Main tank | 189 l / 151 kg | 50 US gal / 333 lbs |
| Auxiliary tank | 138 l / 110 kg | 36.4 US gal / 243lbs |
Specifications apply to standard equipped aircraft, if not otherwise stated. The above data are approximately specifications and may change without notice.
The DA62 is also available with an MTOM of 1,999 kg (4,407 lbs). Our sales team will be happy to provide you with the necessary information: sales@diamondaircraft.com or +43 (2622) 26700-1317.
